Verderair Drum Pump

-Max Flow: 61L/min
-Max pressure: 7 bar
– Max Suction lift dry up to 2.5m
– Max. Suction lift wet up to 4.5m
– Operating Temperature: 107°C
Verderair air operated diaphragm pumps are excellent drum pumps. For the emptying of small barrels, containers, canisters and drums (approx. 200 litres) of all kind of chemicals such as acids or lyes, a double diaphragm pump is a very good alternative to a conventional rod drum pump. Diaphragm pumps can pump corrosive, viscous and abrasive fluids with ease.

LIÊN HỆ VỚI CHÚNG TÔI

Nút số điện thoại liên kết tới Zalo với logo Zalo
Nút số điện thoại liên kết tới Zalo với logo Zalo

TYPE Max. flow Max. discharge pressure Max

Temperature

 Max

Particle size

 Maximum suction lift (dry)
VA15 OD 57 l/m 7 bar  107oC 2,5  mm 4,5 m wc
VA20 OD 61 l/min 7 bar  107oC 2,5  mm 4,5 m wc
